Product Catalog / SHROUDED RH STANDARD TAPER ADAPTER 2BY-RH
No Image Available SHROUDED RH STANDARD TAPER ADAPTER 2BY-RH figure

Associated Figure: SHROUDED RH STANDARD TAPER ADAPTER 2BY-RH

Request a Quote

SHROUDED RH STANDARD TAPER ADAPTER 2BY-RH

Sopko Catalog #: 00181

Product Overview & Dimensions

Providing optimum protection against contamination to the wheelhead nose, these high-quality SHROUDED ADAPTERS are designed for performance.SOPKO assures this standard with quality features like PRECISION GROUND TAPERS and CONCENTRICALLY GROUND AND SQUARE surfaces to maximize cutting conditions and prolong wheel life. Hub OD threads are THREAD GROUND to assure safe, square wheel locking conditions and you can expect years of performance from these adapters because SOPKO HEAT TREATS every one.
Taper 3 in. Taper Per Foot
Large End
('G' Dimension)		 1 in. Large End
Wheel Locking Width
('A' Dimension)		 1/4 - 1
Overall Length
('C' Dimension)		 2-5/8
Thread Size
('D' Dimension)		 1-1/4-16RH

Adapter Configuration

Category Sopko Adapters
Sub-Category Standard Taper Wheel Adapters
Sub-Sub-Category Shrouded Adapters

Threading & Mounting

Thread Direction Right Hand

Additional Features
